PTFE Lined Pipe is involved in manufacturing high-quality Teflon-lined fittings for demanding industrial applications that include corrosive chemicals and high-temperature processes. Having our roots in Ahmedabad, Gujarat we are a well-established supplier of FEP, PFA and PTFE-lined fittings. Our Teflon-lined fittings are created to withstand long usage, chemical resistance and steady performance in extreme environments. With a smooth interior lining strong construction and high sealing effectiveness these fittings provide effective fluid handling and can be designed to suit particular system needs and process requirements.
Teflon-lined fittings are industrial pipe fittings with a Teflon (PTFE) inner coating, a very resistant and non-reactive fluoropolymer. They work best in aggressive chemicals, corrosive chemicals, and high-temperature media without compromising integrity. The Teflon lining provides a smooth, non-stick surface for leak-proof functionality, reducing risk of contamination, and extending the piping system life. Used in applications throughout markets such as chemical processing, pharmaceuticals, food and beverages and water treatment, Teflon-lined fittings find their optimum applications in maintaining purity, enhancing flow efficiency, and assuring safety in aggressive process applications.
Size : 25 NB to 300 NB
Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316
Hydro Test : at 29.8 Kg/cm2
Spark Test : 15 KVA
Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316
Lining : Teflon
PTFE Lined Pipe is a leading supplier of Teflon Lined Pipe Fittings in Ahmedabad, Gujarat, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
NB | ID | RF | OD | PCD | No.Of Holes x Dia Of Holes | Lining Thickness Standard | Lining Thickness Full Vacuum | Length Max. |
| 15 | 10.80 | 34.90 | 88.9 | 60.3 | 4×15.9 | 3.0 | 3.1 | 3000 |
| 20 | 16.00 | 42.70 | 98.4 | 69.8 | 4X15.9 | 3.0 | 3.1 | 3000 |
| 25 | 20.15 | 50.80 | 108.0 | 79.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 40 | 33.90 | 73.00 | 127.0 | 98.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 50 | 45.50 | 92.10 | 152.4 | 120.7 | 4X19 | 3.5 | 4.6 | 3000 |
| 65 | 55.68 | 104.80 | 177.8 | 139.7 | 4×19 | 3.5 | 4.8 | 3000 |
| 80 | 70.90 | 127.00 | 190.5 | 152.4 | 4X19 | 3.5 | 5.0 | 3000 |
| 100 | 94.30 | 157.20 | 228.6 | 190.5 | 8X19 | 4.0 | 5.8 | 3000 |
| 150 | 114.10 | 215.90 | 279.5 | 241.3 | 8X22.2 | 5.0 | 6.8 | 3000 |
| 200 | 195.10 | 269.90 | 342.9 | 298.5 | 8X22.2 | 5.0 | 7.9 | 2000 |
| 250 | 247.40 | 323.90 | 406.4 | 362.0 | 12X25.4 | 5.0 | 8.8 | 2000 |
| 300 | 297.00 | 381.00 | 482.6 | 431.8 | 12X25.4 | 5.0 | 9.0 | **** |
Withstands aggressive acids, alkalis, and solvents without degrading.
Performs reliably in elevated temperature environments up to 260°C.
Ensures tight, secure connections for safe and efficient operation.
Offers durability and reduces maintenance costs in harsh industrial settings.
Yes, the Teflon lining ensures tight seals, effectively preventing leakage and reducing maintenance needs, which contributes to enhanced safety in industrial operations.
Yes, Teflon lined fittings offer exceptional resistance to most strong acids, alkalis, and solvents, making them ideal for use in demanding chemical applications.
Yes, Teflon lined fittings can typically withstand temperatures up to 260°C, depending on the process conditions and pressure requirements.
Teflon lined fittings come in standard sizes ranging from 25mm to 300mm, with custom sizes available upon request to accommodate specific industrial needs.
Teflon lined fittings are primarily used in industries such as chemicals, pharmaceuticals, and food processing, where corrosion resistance and contamination-free flow are essential for maintaining safety and efficiency.
We are the leading Manufacturer and Supplier of PTFE Lined Pipe, Fittings, Flanges, Spool and Valves in Ahmedabad, Gujarat.
